Description
The DS-D4018CS-1F LED display is a high-quality indoor small pitch full-color LED solution designed for clear visuals, seamless performance, and reliable operation. With a P1.8 pixel pitch and SMD Triad LED technology, this display delivers sharp image quality, wide viewing angles, and excellent color consistency. It is ideal for conference rooms, retail spaces, control centers, and indoor digital display applications.
1. Product Details
- Model: DS-D4018CS-1F
- Product Type: Indoor Small Pitch Full Color LED Display
2. Cabinet Specifications
- Pixel Configuration: SMD Triad LED
- Pixel Pitch Category: P1.8
- Pixel Pitch: 1.86 mm
- Pixel Density: 288,906 dots/m²
- Module Configuration: 2 × 3 modules per cabinet
- Cabinet Dimensions: 640 mm × 480 mm × 58.6 mm
- Resolution: 344 × 258 pixels
- Display Area: 0.3072 m²
- Cabinet Weight: 7.55 kg
- Cabinet Material: Die-cast aluminum
- Maintenance: Complete front maintenance
3. Module Specifications
- Module Dimensions: 320 mm × 160 mm
- Module Resolution: 172 × 86 pixels
4. Display Features
- Brightness (White Balance): 600 cd/m²
- Color Temperature: 3000K to 10000K adjustable
- Viewing Angle: 160° (H) / 160° (V)
- Contrast Ratio: 5000:1
- Color Uniformity: ≤ ±0.003 Cx, Cy
- Brightness Uniformity: ≥ 97%
5. Processing Performance
- Driving Method: Constant current driving
- Frame Frequency: 60 Hz
- Refresh Rate: 3840 Hz
- Grey Scale Level: Up to 16-bit
6. Power Consumption
- Maximum Consumption: ≤ 450 W/m²
- Average Consumption: ≤ 150 W/m²
- Input Voltage: 100–240 VAC ±10%
7. Working Environment
- Operating Temperature: -10°C to 40°C
- Operating Humidity: 10% to 60% RH (non-condensing)
8. Storage Conditions
- Storage Temperature: -20°C to 60°C
- Storage Humidity: 10% to 85% RH (non-condensing)
9. General Information
- Package Dimensions: 758 mm × 606 mm × 442 mm
Why Choose DS-D4018CS-1F LED Display?
This indoor small pitch LED display offers excellent clarity, high brightness, and reliable performance for professional indoor applications. With its compact cabinet design, front maintenance feature, and energy-efficient operation, it is an ideal solution for environments that require high-quality visuals, durability, and seamless display performance.
